LOW BAY FLEX 1500 DALI DALI P 105W 840 OV
Industry
LOW BAY FLEX 1500 DALI DALI P 105W 840 OV
Manufacturer Ref:
4099854163975
Nortécnica Ref:
EAN:
4099854163975
Description
Technical Information
Attributes
Mounting method
-
EF000004
I
Width
115.00
Outer diameter
-
Reflector
None
Lamp holder
None
Conductor cross section
-
Connection type
-
Housing colour
White
Voltage type
AC
Suitable for lamp power
-
Type of control gear
-
Colour rendering index CRI
80-89
EF001263
No
Number of poles
7
Length
1527.00
Heightdepth
65.00
Housing material
-
Lamp type
LED not exchangeable
Reflector colour
-
Suitable for emergency lighting
No
Light distribution
Symmetric
Material reflector
-
Impact strength
IK08
Nominal voltage
220
240
Emergency power supply integrated
No
Degree of protection IP
IP23
With protective cover
No
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Suitable for number of light sources
0
With control gear
Yes
Beam angle
-
Nominal current
450
450
Colour temperature
4000
4000
Max. system power
105
EF009349
16800
Colour of light
White
Constant light output CLO
No
Type of wiring
Suitable for loop-through wiring
Rated lifetime L70B50 at 25 C
100000
Colour consistency McAdam ellipse
-
EF011947
-
Photobiological safety according to EN 62471
RG1
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
-25
+50
Filament test according to IEC 60695-2-11
-
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
Yes
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
No
Light distributor
Diffuser lens/optic/panel
EF012172
160
Dimming DSI
No
Suitable for auxiliary lamp
No
Operation by Bluetooth
No
Max. number of luminaires per miniature circuit breaker C16 MCB
28
Max. number of luminaires per miniature circuit breaker B16 MCB
27
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 100,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
-
Failure rate at median useful life of 100,000 h at 25 C ambient tq
-
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
No
Energy efficiency class of the light source according to EU regulation 20192015
D
Power factor
0.90
Meets min. EIA lifetime criterion L90 at 50,000 hours at tq 25 C
Yes
Brands
LEDVANCE
Technical Sheet
