9514 Movement detector mini 360º
Motion and Presence Detectors
9514 Movement detector mini 360º
Manufacturer Ref:
2CLA951400A1001
Nortécnica Ref:
EAN:
8427238095110
Description
Technical Information
Attributes
Mounting method
-
Colour
White
Width
58
Model
Presence detector
Halogen free
Yes
Height
100
Depth
130
Connection type
-
Surface protection
Untreated
Creep-under protection
Yes
Voltage type
AC
Switching-on delay
60
Switch-off delay
900
Built-in depth
77
Frequency
-
-
With remote control
No
Diameter
38
Suitable for wall mounting
No
Built-in width
0
Built-in diameter
32
Staircase light controller
-
Bridging switch
-
Suitable for wireless transmission
No
Material quality
Thermoplastic
Max. reach frontally
-
Max. reach sideways
-
Max. switching power
2000
EF001731
0
45
Max. starting current
80
Material
Plastic
Response value sensitivity adjustable
Yes
Connection cable length
-
Dim function with dimmer basic element
No
Response value luminosity
10
1000
Suitable for C-load
-
Diameter reach on floor
6
Remote operation
No
HVAC-control
No
Constant light control
No
Substation input
Yes
RAL-number similar
9010
With signal unit
No
Control current
4500
Teach-function for response value luminosity
No
Networkable
No
Forced switch off
No
Scan angle
360
Built-in length
-
Impact strength
-
With connection cable
-
Nominal voltage
230
230
Degree of protection IP
IP20
With alarm function
No
Transparent
No
Animal zone
No
Surface finishing
Matt
Detection angle horizontal
-
-
Min. switch-on time
60
Max. duty cycle
15
Response value luminosity adjustable
Yes
Optimum mounting height
3
Pivoting range sensor, horizontal
0
0
Pivoting range sensor, vertical
0
0
Number of switching zones
-
With DALI interface
No
IFTTT support available
No
Forced switch on
No
Min. starting current
-
Min. depth of built-in installation box
77
Max. presence range
113.09724
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. switching power LED
-
Background monitoring
-
With acoustic sensor
-
EF020270
EV007611
Suitable for ceiling mounting
Yes
Anti-bacterial treatment
No
Brands
ABB
