Electronic movement detector for detecting thermal motion. Remote operation via IR remote control 6841-101. Remote configurable via IR service remote control 6842-101. With display for detection and operation mode. With ground and rear-field detection. With high-quality lens for optimum detection. Detection sensitivity adjustable via IR service remote control. Surveillance density: 84 sectors with 336 switching segments. With integrated dismantling protection. All functions controlled by microprocessor. Continuous light (4 hours), light deactivation (4 hours) and presence simulation can be activated via IR remote control. Reading in the current brightness value as switching threshold via remote control. With automatic range stabilization. With automatic interference suppression. With automatic dazzle-proofing. With brightness-independent test mode for evaluating the detection zone. Individual adjustment of detection range via enclosed protective foil which can be cut to size. Additional possibility for switch-on via normally open push-button switch. Switch-off delay: 10 sec to 30 min or short-time pulse 1 sec adjustable.
Motion and Presence Detectors
MasterLINE 220 Motion Detector brown
Nortécnica Ref:
EAN:
4011395150580
Description
Technical Information
Attributes
Mounting method
Surface mounted
Colour
Brown
Width
115
Model
Movement sensor
Halogen free
Yes
Height
125
Depth
141
Connection type
-
Surface protection
Untreated
Creep-under protection
Yes
Voltage type
-
Switch-on delay
0
Switch-off delay
-
Built-in depth
0
Frequency
50
60
With remote control
No
Diameter
-
Suitable for wall mounting
Yes
Built-in width
-
Built-in diameter
-
Staircase light controller
Yes
Bridging switch
No
Suitable for wireless transmission
No
Material quality
Thermoplastic
Max. reach frontally
16
Max. reach sideways
16
Max. switching power
3680
EF001731
-25
55
Max. starting current
-
Material
-
Response value sensitivity adjustable
Yes
Connection cable length
-
Dim function with dimmer basic element
No
Response value luminosity
0
1000
Suitable for C-load
-
Diameter reach on floor
32
Remote operation
Yes
HVAC-control
No
Constant light control
No
Substation input
No
RAL-number similar
8017
With signal unit
No
Control current
-
Teach-function for response value luminosity
No
Networkable
No
Forced switch off
Yes
Scan angle
-
Built-in length
-
Impact strength
-
With connection cable
-
Nominal voltage
230
230
Degree of protection IP
IP55
With alarm function
No
Transparent
No
Animal zone
No
Surface finishing
Matt
Detection angle horizontal
8
220
Min. switch-on time
10
Max. duty cycle
30
Response value luminosity adjustable
Yes
Optimum mounting height
2.5
Swivel range sensor, horizontal
-30
30
Swivel range sensor, vertical
-10
10
Number of switching zones
1
With DALI interface
No
IFTTT support available
No
Forced switch on
Yes
Min. starting current
-
Min. depth of built-in installation box
0
Max. presence range
-
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. switching power LED
-
Background monitoring
-
With acoustic sensor
-
Sensor type
EV007611
Suitable for ceiling mounting
No
Anti-bacterial treatment
No
Brands
ABB
Descrição Longa
Electronic movement detector for detecting thermal motion. Remote operation via IR remote control 6841-101. Remote configurable via IR service remote control 6842-101. With display for detection and operation mode. With ground and rear-field detection. With high-quality lens for optimum detection. Detection sensitivity adjustable via IR service remote control. Surveillance density: 84 sectors with 336 switching segments. With integrated dismantling protection. All functions controlled by microprocessor. Continuous light (4 hours), light deactivation (4 hours) and presence simulation can be activated via IR remote control. Reading in the current brightness value as switching threshold via remote control. With automatic range stabilization. With automatic interference suppression. With automatic dazzle-proofing. With brightness-independent test mode for evaluating the detection zone. Individual adjustment of detection range via enclosed protective foil which can be cut to size. Additional possibility for switch-on via normally open push-button switch. Switch-off delay: 10 sec to 30 min or short-time pulse 1 sec adjustable.
