TeSys K control relay - 2 NO 2 NC - 690 V - 72 V DC low consumption coil
Contactors, Motor Circuit Breakers and Accessories
TeSys K control relay - 2 NO 2 NC - 690 V - 72 V DC low consumption coil
Manufacturer Ref:
CA4KN22SW3
Nortécnica Ref:
EAN:
3389110485349
Description
Technical Information
Attributes
Mounting method
DIN-rail/screw
Width
45
Height
77
Depth
93
Interface
No
Number of auxiliary contacts as normally open contact
2
Number of auxiliary contacts as normally closed contact
2
Rated operation current Ie, 400 V
10
Suitable for manual operation
No
Number of auxiliary contacts as change-over contact
0
Rated control supply voltage AC 50 Hz
-
-
Rated control supply voltage AC 60 Hz
-
-
Rated control supply voltage DC
72
72
Voltage type operating voltage
AC
With LED indication
No
Rated switch current
0.005
Connection type auxiliary circuit
Screw connection
Number of auxiliary contacts as normally closed contact, delayed switching
0
Number of auxiliary contacts as normally open contact, leading
0
Rated operation current
10
Operating voltage AC 50 Hz
690
690
Operating voltage AC 60 Hz
690
690
Operating voltage DC
-
-
Voltage type for actuating
DC
Brands
Schneider
