Remote switch with 1 NO contact contact for 230V AC 16A control 115V AC
Management and Measuring Devices
Remote switch with 1 NO contact contact for 230V AC 16A control 115V AC
Manufacturer Ref:
5TT41011
Nortécnica Ref:
EAN:
4001869312392
Description
Technical Information
Attributes
Mounting method
DIN rail
Function
Mechanical switch
Built-in depth
70
Width in number of modular spacings
1
Control voltage 1
92
Control voltage 2
-
Type of control voltage 1
AC
Type of control voltage 2
ACDC
Frequency control voltage 1
50
Frequency control voltage 2
-
Suitable for manual operation
Yes
Voltage type supply voltage
AC
Supply voltage
250
Max. switching current cos phi 0.6
16
Max. incandescent lamp load
2000
Max. load fluorescent lamp
500
Max. load fluorescent lamp Duo circuit
900
Max. load fluorescent lamp parallel compensated
400
Rated switch current
16
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Brands
Siemens AG
Technical Sheet
