LS45P13B11 is a 40 mm wide, standard reinforced Limit Switch made of fiber-glass reinforced UL-V0 material, with 4 mounting holes at the top and bottom, 1 1/2'' NPT cable entry on the bottom, steel roller plunger actuator and 1 N.O + 1 N.C snap action (Zb type) contacts
Electromechanical and Electronic Sensors
LS45P13B11 Limit Switch
Nortécnica Ref:
EAN:
3471522611451
Description
Technical Information
Attributes
Switching function
Quick-break switch
Corrente nominal de operação Ie em AC-15, 230 V
3.1
Corrente nominal de operação Ie em DC-13, 230 V
0.4
Housing material
Plastic
Suitable for safety functions
No
Coating housing
Other
With status indication
No
Type of interface for safety communication
None
Type of electric connection
Connector 1/2 inch
Explosion safety category for gas
None
Explosion safety category for dust
None
Construction type housing
Cuboid
Degree of protection IP
IP65
Forced opening
No
Número de contatos auxiliares de segurança
0
Type of control element
Plunger
Type of interface
None
Output electronic
No
Corrente nominal de operação em AC-15, 125 V
5.5
Corrente nominal de operação em AC-15, 24 V
10
Corrente nominal de operação em DC-13, 125 V
0.6
Corrente nominal de operação em DC-13, 24 V
6
Sensor de largura
41
Sensor de diâmetro
0
Altura do sensor
117
Comprimento do sensor
41
Switching function latching
No
Ambient temperature during operating
-25
70
Number of contacts as normally closed contact
1
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Alignment of the control element
Other
Degree of protection NEMA
-
Brands
ABB
Descrição Longa
LS45P13B11 is a 40 mm wide, standard reinforced Limit Switch made of fiber-glass reinforced UL-V0 material, with 4 mounting holes at the top and bottom, 1 1/2'' NPT cable entry on the bottom, steel roller plunger actuator and 1 N.O + 1 N.C snap action (Zb type) contacts
