Orion3 Light Grids, Passive unit, 3 beams, Protected height=800mm. Orion3 Base and Extended are light grids with a sturdy profile for access protection. Only one of the parts needs power supply, since both transmitter and receiver are in the same active part. The other part is passive with mirrors to reflect the beams. With 2-4 beams and an operating range of up to 8 m, it is intended for body detection.
Electromechanical and Electronic Sensors
Orion3-4-M2C-080 Safety light grid - Passive part
Nortécnica Ref:
EAN:
7350024481860
Description
Technical Information
Attributes
Voltage type
Other
Cascadable
No
Suitable for safety functions
Yes
Ambient temperature
0
55
Número de saídas semicondutoras com função de sinalização
0
Número de saídas energizadas por contato com função de sinalização
0
Número de saídas semicondutoras protegidas
0
Número de saídas energizadas por contato protegido
0
Fade-out possible
-
Type of interface for safety communication
Other
Type of switching output of the OSSD
Other
Type of electric connection
Other
Rated control supply voltage AC 50 Hz
-
-
Rated control supply voltage AC 60 Hz
-
-
Rated control supply voltage DC
0
24
Operation agentsafety class
-
Capacidade de deteção para corpos de prova
400
Explosion safety category for gas
None
Explosion safety category for dust
None
Scope of delivery of the oneway system
Receiver
Corrente de saída max. na saída protegida
-
With monitoring function downstream switching devices
-
With restart blockage
-
With muting function
-
Override possible
-
Tempo de reação
-
Reduced resolution
No
Intervalo de transmissão do campo de segurança
8
Tensão de comutação do OSSD no estado "alto"
-
Altura do campo de proteção
800
Type of safety according to IEC 614961
4
With beam coding
-
Clock control possible
-
Comprimento de onda do sensor
-
Degree of protection IP
IP65
Resolução da cortina de luz
399.8
Sensor de largura
52
Altura do sensor
6.4
Comprimento do sensor
56.9
Degree of protection NEMA
-
Brands
ABB
Descrição Longa
Orion3 Light Grids, Passive unit, 3 beams, Protected height=800mm.
Orion3 Base and Extended are light grids with a sturdy profile for access protection. Only one of the parts needs power supply, since both transmitter and receiver are in the same active part. The other part is passive with mirrors to reflect the beams. With 2-4 beams and an operating range of up to 8 m, it is intended for body detection.
