Rated voltage: 230 Vac ± 10% / 50-60 Hz For wireless switching of electrical loads. 2 functions: ON/OFF switch or time delayed switch. For wall mounted transmitter code: 8531.1 &8531.2. Switch-off delay: 3 sec. / 1 min. / 5 min. / 15 min. Repeater function can be activated for extended range. For universal attachment or installation. 3 wire connection (neutral conductor required). With auxiliary input for push-buttons code: 8104.X. Send/receive frequency: 868 MHz. Free-field range: approx. 100 m. Control element: adjustable potentiometer Display elements: status indication of output via LED. Outputs: 1x Normally Open or Normally closed contact, 230 Vac Rated power: - Incandescent, halogen, electronic transformer and ferromagnetic transformers: 2.300 W/VA - Fluorescent load: 1.000 VA Temperature range (Device): -5 °C to 45 °C Dimensions: (L x W x D): 47 mm x 48 mm x 22 mm
Description
Technical Information
Attributes
Mounting method
Other
Colour
-
Halogen free
Yes
Surface protection
-
Current supply
230 V AC
Power consumption
-
Number of relays
1
Suitable for switch
Yes
Suitable for pulse button
No
Suitable for dimmer
No
Suitable for roller shutter switch
No
Material quality
-
Material
-
Type of fastening
-
Modulation
-
Rolling code system
No
Number of commands
-
Radio frequency
-
In housing
Yes
In tube base housing
No
Printed circuit boardmodule
No
Push button mode
Yes
Switching mode
Yes
With manual radio transmitter
Yes
With radio coding device
No
With radio controlled push button
Yes
Code length Bit
-
Suitable for venetian-roller shutter switch
No
Suitable for venetian shutter switch
No
Número RAL semelhante
-
Transparent
No
Surface finishing
-
Suitable for degree of protection IP
IP20
IFTTT support available
No
Degree of protection NEMA
-
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Brands
ABB
Descrição Longa
Rated voltage: 230 Vac ± 10% / 50-60 Hz
For wireless switching of electrical loads.
2 functions: ON/OFF switch or time delayed switch.
For wall mounted transmitter code: 8531.1 &8531.2.
Switch-off delay: 3 sec. / 1 min. / 5 min. / 15 min.
Repeater function can be activated for extended range.
For universal attachment or installation.
3 wire connection (neutral conductor required).
With auxiliary input for push-buttons code: 8104.X.
Send/receive frequency: 868 MHz.
Free-field range: approx. 100 m.
Control element: adjustable potentiometer
Display elements: status indication of output via LED.
Outputs: 1x Normally Open or Normally closed contact, 230 Vac
Rated power:
- Incandescent, halogen, electronic transformer and ferromagnetic transformers: 2.300 W/VA
- Fluorescent load: 1.000 VA
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 47 mm x 48 mm x 22 mm
