S202MT-D4 MiniatureCircuitBreaker D-Char.,10kA,4A,2P
Cutting and Protection Devices
S202MT-D4 Miniature Circuit Breaker - 2P - D - 4 A
Nortécnica Ref:
EAN:
4016779875387
Description
Technical Information
Attributes
Voltage type
AC
Built-in depth
69
Rated current
4
EF000228
400
Frequency
50
60
Release characteristic
D
Rated insulation voltage Ui
440
Current limiting class
3
Overvoltage category
3
Pollution degree
3
Width in number of modular spacings
2
Explosion-proof
No
Power loss
3.4
Degree of protection IP
IP20
Number of protected poles
2
Concurrently switching neutral conductor
No
Connectable conductor cross section solid-core
0.75
35
Connectable conductor cross section multi-wired
0.75
25
Ambient temperature during operating
-25
55
Flush-mounted installation
No
Additional equipment possible
Yes
Number of poles total
2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
15
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
15
Rated impulse withstand voltage Uimp
4
Brands
ABB
Descrição Longa
S202MT-D4 MiniatureCircuitBreaker D-Char.,10kA,4A,2P
