Signaling contacts SK1-ARK with Push-in spring terminals signal the tripping of the manual motor starter. For SK1-ARK a red flag in a window on the front of the device indicates the tripping event. The contact positions of SK1-AR don't need to be manually reset after a tripping. They are reset to their original position when the manual motor starter is switched back on. The SK1-ARK signaling contacts signal tripping regardless if it was caused by short-circuit, overload or electrical release (AA1 or UA1). They are attached on the right side of the manual motor starter. Signaling contacts SK1-ARK are available as normally open or normally closed contacts.
Cutting and Protection Devices
SK1-02ARK Signaling Contact, 2NC with Push-in Spring terminals
Nortécnica Ref:
EAN:
4013614561368
Description
Technical Information
Attributes
Mounting method
Side mounting
Model
Clip-on
Lamp holder
None
Corrente nominal de operação Ie em AC-15, 230 V
4
Type of electric connection
Spring clamp connection
Number of fault-signal switches
1
Número de contatos como contato normalmente fechado
2
Número de contatos como contato normalmente aberto
0
Número de contatos como inversores
0
Brands
ABB
Descrição Longa
Signaling contacts SK1-ARK with Push-in spring terminals signal the tripping of the manual motor starter. For SK1-ARK a red flag in a window on the front of the device indicates the tripping event. The contact positions of SK1-AR don't need to be manually reset after a tripping. They are reset to their original position when the manual motor starter is switched back on. The SK1-ARK signaling contacts signal tripping regardless if it was caused by short-circuit, overload or electrical release (AA1 or UA1). They are attached on the right side of the manual motor starter. Signaling contacts SK1-ARK are available as normally open or normally closed contacts.
