PIR movement detectors Nr.contacts: 1 Contacts configuration: NO Contact Material: AgSnO2 Nominal voltage: 230 V. Mounting method: Flush mounted (plaster) Colour: Anthracite Model: Movement sensor Halogen free: yes Connection type: Screwed terminal Voltage type: AC Frequency: from 50 to 60 Hz. With remote control: no Staircase monitoring: no Suitable for wireless transmission: no Material quality: Thermoplastic Max. switching power: 200 W. Temperature: from -10 to 50 °C. Material: Plastic Response value sensitivity adjustable: yes Dim function with dimmer basic element: no Response value luminosity: from 1 to 500 lx. Suitable for C-load: yes Remote operation: no HVAC-control: no Constant light control: no Substation input: no RAL-number (similar): 9010 With signal unit: yes Networkable: no Forced switch off: yes With alarm function: no Transparent: no Animal zone: no Surface finishing: Matt Min. switch-on time: 10 s. Max. duty cycle: 20 min. Suitable for wall mounting: yes Response value luminosity adjustable: yes With DALI interface: no Forced switch on: no Sensor type: Passive infrared Suitable for ceiling mounting: no Anti-bacterial treatment: no Protection category: IP20 Note: Light ON time after last detection: 10s...20min
Motion and Presence Detectors
PIR MOVEMENT DETECTOR 110
Nortécnica Ref:
EAN:
8012823416649
Description
Technical Information
Attributes
Nominal voltage
230
Mounting method
Flush-mounted
Colour
Anthracite
Width
22.5
Model
Movement sensor
Halogen free
Yes
Height
42
Depth
45.5
Connection type
Screwed terminal
Surface protection
Creep-under protection
No
Voltage type
AC
Switch-on delay
-
Switch-off delay
-
Built-in depth
-
Frequency
50
60
With remote control
No
Diameter
-
Suitable for wall mounting
Built-in width
-
Built-in diameter
-
Staircase light controller
No
Bridging switch
No
Suitable for wireless transmission
No
Material quality
Thermoplastic
Max. reach frontally
-
Max. reach sideways
-
Max. switching power
200
EF001731
Array
Max. starting current
-
Material
Plastic
Ambient temperature
Response value sensitivity adjustable
Yes
Connection cable length
Dim function with dimmer basic element
No
Response value luminosity
1
500
Suitable for C-load
Yes
Diameter reach on floor
-
Remote operation
No
HVAC-control
No
Constant light control
No
Substation input
No
RAL-number similar
9010
With signal unit
Yes
Control current
-
Teach-function for response value luminosity
No
Networkable
No
Forced switch off
Yes
Scan angle
-
Built-in length
-
Impact strength
With connection cable
Nominal voltage
Degree of protection IP
IP20
With alarm function
No
Transparent
No
Animal zone
No
Surface finishing
Matt
Detection angle horizontal
-
-
Min. switch-on time
10
Max. duty cycle
20
EF006644
true
Response value luminosity adjustable
Yes
Optimum mounting height
-
Swivel range sensor, horizontal
-
-
Swivel range sensor, vertical
-
-
Number of switching zones
-
With DALI interface
IFTTT support available
No
Forced switch on
No
Min. starting current
-
Min. depth of built-in installation box
-
Max. presence range
-
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. switching power LED
200
Compatible with Casambi
Background monitoring
With acoustic sensor
Ceiling built-in mounting without installation box
Movement sensorpresence detector technology
Sensor type
Suitable for ceiling mounting
No
Anti-bacterial treatment
No
Brands
80127
Long Description
PIR movement detectors Nr.contacts: 1 Contacts configuration: NO Contact Material: AgSnO2 Nominal voltage: 230 V. Mounting method: Flush mounted (plaster) Colour: Anthracite Model: Movement sensor Halogen free: yes Connection type: Screwed terminal Voltage type: AC Frequency: from 50 to 60 Hz. With remote control: no Staircase monitoring: no Suitable for wireless transmission: no Material quality: Thermoplastic Max. switching power: 200 W. Temperature: from -10 to 50 °C. Material: Plastic Response value sensitivity adjustable: yes Dim function with dimmer basic element: no Response value luminosity: from 1 to 500 lx. Suitable for C-load: yes Remote operation: no HVAC-control: no Constant light control: no Substation input: no RAL-number (similar): 9010 With signal unit: yes Networkable: no Forced switch off: yes With alarm function: no Transparent: no Animal zone: no Surface finishing: Matt Min. switch-on time: 10 s. Max. duty cycle: 20 min. Suitable for wall mounting: yes Response value luminosity adjustable: yes With DALI interface: no Forced switch on: no Sensor type: Passive infrared Suitable for ceiling mounting: no Anti-bacterial treatment: no Protection category: IP20 Note: Light ON time after last detection: 10s...20min
