Energy meters Model: Direct measurement Suitable for: Purchase/supply Type of indication: Digital Frequency: from 50 to 60 Hz. Max. current (Imax): 40 A. Width in number of modular spacings: 1 Number of positions total (counter): 7 Type of meter: Electronic Protection category: IP50 Type of interface: None Energy type: Effective power and blind power Tariff type: One-tariff Escapement mechanism: yes Calibrated: yes Pulse output: Electrical Pulse type: S0 Pulse rate: 1000 Imp/kWh (kvarh). Accuracy class: B Pole type: Single phase With lock code: yes Nominal voltage (Un) N-L: from 184 to 265 V. Nominal current (In): 5 A.
Management and Measuring Devices
ENERGY METER NOT MID CERTIFIED
Nortécnica Ref:
EAN:
8012823426716
Description
Technical Information
Attributes
Mounting method
Largura
17.5
Model
Direct measurement
Altura
90.4
Profundidade
63.9
Suitable for
Purchase/supply
Type of indication
Digital
Power consumption
Frequency
50
60
Max. current Imax
40
Width in number of modular spacings
1
Número total de posições contador
7
Type of meter
Electronic
Degree of protection IP
IP50
Type of interface
None
Energy type
Effective power and reactive power
Tariff type
One-tariff
Tariff control
Escapement mechanism
Yes
Calibrated
Yes
Approval
Pulse output
Electrical
Pulse type
S0
Pulse rate
1000
1000
Accuracy class
B
Pole type
Single phase
Measurement type load profile
No
EEC40 signature
No
With lock code
Yes
Nominal voltage Un N-L
184
265
Nominal voltage Un L-L
-
-
Nominal current In
5
Degree of protection NEMA
