Limit. sobret. 1P 40kA T2 IT
Surge Arresters
Limit. sobret. 1P 40kA T2 IT
Nortécnica Ref:
EAN:
3250615515209
Description
Technical Information
Attributes
Mounting method
On basic element
With remote signalling contact
No
Number of conductors without earthing
1
Construction size
1 modular spacing
Nível de proteção de tensão
2.2
Tensão máxima contínua AC
440
Corrente de descarga nominal 820
20
Tensão nominal CA
400
Tensão nominal DC
-
Category type 2
Yes
Nível de proteção L-N
2.2
Signalling at the device
Optical
Máxima tensão DC contínua
-
Degree of protection IP
IP20
Tensão fotovoltaica máx.
0
Nível de proteção de tensão N-PE
-
Integrated backup fuse
No
Secção do condutor rígido máx. monomulti filamento
35
Secção flexível do condutor máx. fio fino
25
System configuration DC
No
System configuration IT
Yes
System configuration TN
No
System configuration TN-C
No
System configuration TN-S
No
System configuration TT
No
System configuration other
No
System configuration TN-C-S
No
Corrente de choque de descarga máxima 820
40
Resistência a curto-circuito Isccr
25
Proteção de sobreintensidade máx. Ligação em paralelo fusível
125
Proteção de sobreintensidade máx. Ligação em série fusível
80
Integrated short-circuit protection
No
Proteção contra curto-circuitos seletiva integrada - por fusível gG
125
Leakage-current free
No
Brands
Hager
Long Description
Limit. sobret. 1P 40kA T2 IT
