Interruptor crepuscular com sonda para exterior
Management and Measuring Devices
Interr. crepuscular c sonda p exterior
Nortécnica Ref:
71EEN100
EAN:
3250617579308
Description
Technical Information
Attributes
Mounting method
DIN rail
Built-in depth
17.8
Rated voltage
230
Rated frequency
50
60
Largura em número de módulos
1
Rated voltage light sensor
230
Max. switching current cos phi 0.6
10
Max. incandescent lamp load
2300
Max. conductor length light sensor
100
Max. load fluorescent lamp
1000
Max. load fluorescent lamp Duo circuit
1000
Max. load fluorescent lamp parallel compensated
1000
With programmable overnight shutoff
No
Degree of protection IP light sensor
IP55
Push button input
No
Degree of protection IP
IP20
Rated switch current
10
Adjustment range brightness value
5
2000
Protection class light sensor
II
Mounting method light sensor
Other
Max. switching power LED
-
Brands
Hager
