MCRA031AR6 Mini Contactor Relay 220 ... 230 V AC - 0 NO - 0 NC - Ring-Tongue Terminals
Contactors, Motor Circuit Breakers and Accessories
MCRA031AR6 Mini Contactor Relay 220 ... 230 V AC - 0 NO - 0 NC - Ring-Tongue Terminals
Manufacturer Ref:
1SAH102181R9900
Nortécnica Ref:
EAN:
4013614547744
Description
Technical Information
Attributes
Mounting method
DIN rail
Width
45
Height
48
Depth
56
Interface
No
Number of auxiliary contacts as normally open contact
3
Number of auxiliary contacts as normally closed contact
1
Rated operation current Ie, 400 V
4
Suitable for manual operation
No
Number of auxiliary contacts as change-over contact
0
Rated control supply voltage AC 50 Hz
220
230
Rated control supply voltage AC 60 Hz
220
230
Rated control supply voltage DC
-
-
Voltage type operating voltage
AC
With LED indication
No
Rated switch current
6
Connection type auxiliary circuit
Screw connection
Number of auxiliary contacts as normally closed contact, delayed switching
0
Number of auxiliary contacts as normally open contact, leading
0
Rated operation current
6
Operating voltage AC 50 Hz
690
690
Operating voltage AC 60 Hz
690
690
Operating voltage DC
440
440
Voltage type for actuating
AC
Brands
ABB
