Barra equipotencial BigBar 5 conexões 5xM10 Cobre
Equipotential Bonding Bar
Barra equipotencial BigBar 5 conexões 5xM10 Cobre
Manufacturer Ref:
5015830
Nortécnica Ref:
255015830
EAN:
4012195002253
Description
Technical Information
Attributes
Width
40
Model
Only clamp
Height
5
Construction type
Surface mounting fix
Length
246
Number of connections flat conductor 30 mm
0
Number of connections flat conductor 40 mm
0
Number of connections conductor to 16 mm² fixed
0
Number of connections conductor to 25 mm² fixed
0
Number of connections conductor to 6 mm² fixed
0
Number of connections conductor to 95 mm² fixed
0
Number of connections round conductor 10 mm
0
Number of connections round conductor 8 mm
0
Number of connections round conductor 8-10 mm
0
Explosion-tested version
-
Insulator
Yes
Surface of the clamp
-
Surface of the contact rail
-
Material of clamp
Copper
Material of contact rail
Copper
Number of connections round conductor total
5
Brands
80686
Technical Sheet
