Descarregador de sobretensões iPRD 40r 800 PV 2P
Surge Arresters
Descarregador de sobretensões iPRD 40r 800 PV 2P
Manufacturer Ref:
A9L40271
Nortécnica Ref:
51A9L40271
EAN:
3606480506666
Description
Technical Information
Attributes
Mounting method
DIN rail (top hat rail) 35 mm
With remote signalling contact
Yes
Number of conductors without earthing
2
Construction size
3 modular spacing
Voltage protection level
3
Tensão máxima contínua AC
-
Corrente de descarga nominal 820
15
Tensão nominal CA
-
Tensão nominal DC
800
Category type 2
Yes
Nível de proteção L-N
3
Signalling at the device
Optical
Máxima tensão DC contínua
800
Degree of protection IP
IP20
Max. PV-voltage
800
Voltage protection level N-PE
3
Integrated backup fuse
No
Max. conductor cross section solid solid, stranded
35
Max. conductor cross section flexible fine-strand
35
System configuration DC
Yes
System configuration IT
No
System configuration TN
No
System configuration TN-C
No
System configuration TN-S
No
System configuration TT
No
System configuration other
No
System configuration TN-C-S
No
Max. discharge surge current 820
40
Short-circuit breaking capacity Isccr
-
Max. overcurrent protection device, parallel connection fuse
-
Max. overcurrent protection device, series connection fuse
-
Integrated short-circuit protection
No
Integrated short-circuit protection selective to fuse gG
-
Leakage-current free
No
Brands
Schneider
