Livinglight - botão de pressão duplo 1P NA 10A branco
Switches, Dimmers, and Buttons
Livinglight - botão de pressão duplo 1P NA 10A branco
Manufacturer Ref:
N4036N
Nortécnica Ref:
EAN:
8005543712900
Description
Technical Information
Attributes
Nominal voltage
250
Mounting method
Module frame
Assembly arrangement
Basic element
Method of operation
Push button
Colour
White
Model
Single push button
Halogen free
Yes
Connection type
Screwed terminal
Imprint
None
Surface protection
Untreated
With signal lamp
No
Rated current
10
Label spaceinformation surface
No
Monitoring contact
No
Material quality
Thermoplastic
Number of poles
2
Material
Plastic
Type of fastening
Engage (snap)
Number of rockers
2
With lighting
Yes
RAL-number similar
9003
Operating principle
-
Impact strength
IK04
With light source
No
Transparent
No
Surface finishing
Matt
Suitable for degree of protection IP
IP20
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
2
Number of contacts as change-over contact
0
Device width
22
Device height
44
Device depth
36.5
Number of modules module system
1
IFTTT support available
No
Min. depth of built-in installation box
35.5
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Number of revolving contacts
0
Contactless type
No
Anti-bacterial treatment
No
Brands
Legrand
Technical Sheet
