CAIXA DE APARELHAGEM SIMPLES REDUZIDA Ø68 - 68x41,5 PARA PAREDES OCAS VERDE
Boxes
CAIXA DE APARELHAGEM SIMPLES REDUZIDA Ø68 - 68x41,5 PARA PAREDES OCAS VERDE
Manufacturer Ref:
56101P
Nortécnica Ref:
42056101P
EAN:
5607353012886
Description
Technical Information
Attributes
Mounting method
Hollow wall
Colour
Green
Largura
-
Model
Single
Halogen free
Yes
Shape
Round
Surface protection
Untreated
Diâmetro
68
Equipped with
Clamp
Construction type
Cable junction box
Inner depth
-
Couplable
Yes
Comprimento
-
Sealable
No
Circuit integrity
None
Material
Plastic
Number of inlets
8
Mounting switching equipment
Screw or spread out
Cover attachment
Screwed
For number of device inserts
1
Luminaire hook mounting
No
Max. conductor cross section
2,5
With screening
No
EF005060
No
With screws
Yes
Airtight
-
Depth
41
42
Suitable for cable diameter
1.5
2.5
Degree of protection IP
IP20
For tube diameter
20 mm
Inlet from the rear
Yes
Pipe locking
No
Special application
None
Clamp position fixed
-
Number of poles of the clamp
-
Nozzle
Other
Provided with revolving ring
No
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
Pipe locking optional
No
Number of included spouts
-
Cover model
None
Housing feed-through by break-out opening
Yes
Transparent cover
No
Degree of protection NEMA
-
Suitable for wallboard thickness
-
-
Brands
TEV2 Dist Mat Electrico Lda
Technical Sheet
