Caixa de derivação 80x43x34 Polietileno branco puro RAL 9010
Boxes
Caixa de derivação 80x43x34 Polietileno branco puro RAL 9010
Manufacturer Ref:
2000005
Nortécnica Ref:
252000005
EAN:
4012195917083
Description
Technical Information
Attributes
Mounting method
Wall-/ceiling mounting
Colour
White
Largura
43
Model
Junction box
Halogen free
Yes
Depth
36
Shape
Square
Surface protection
-
Diâmetro
-
Equipped with
None
With strain relief
-
Rated insulation voltage Ui
690
Número de polos
-
Comprimento
80
Sealable
No
Circuit integrity
None
Working temperature
-5
45
Material
Plastic
Number of clamp positions per pole
-
Number of inlets
10
RAL-number similar
9010
Explosion-tested version
No
Cover attachment
Snapped on
Max. conductor cross section
2.5
With screening
No
Weatherproof
No
Degree of protection IP
IP55
For tube diameter
-
Inlet from the rear
No
For Ex-zone gas
None
Connectable
Yes
Type of housing feed-through
Preembossing
For Ex-zone dust
None
Cover model
Blind cover
Castable
No
Casting compound included
No
Transparent cover
No
Degree of protection NEMA
-
Mounting in the soil
No
Mounting under water
No
Outgoing connections with connectors for plug-in building installation
-
Number of cable glands included
-
Brands
OBO
Technical Sheet
