Caixa de derivação 85x85x40 Polietileno branco puro RAL 9010
Boxes
Caixa de derivação 85x85x40 Polietileno branco puro RAL 9010
Manufacturer Ref:
2000180
Nortécnica Ref:
252000180
EAN:
4012195707899
Description
Technical Information
Attributes
Mounting method
Wall-/ceiling mounting
Colour
White
Largura
85
Model
Junction box
Halogen free
Yes
Depth
40
Shape
Square
Surface protection
-
Diâmetro
-
Equipped with
None
With strain relief
-
Rated insulation voltage Ui
690
Número de polos
-
Comprimento
85
Sealable
No
Circuit integrity
None
Working temperature
-5
45
Material
Plastic
Number of clamp positions per pole
-
Number of inlets
12
RAL-number similar
9010
Explosion-tested version
No
Cover attachment
Snapped on
Max. conductor cross section
2.5
With screening
No
Weatherproof
No
Degree of protection IP
IP55
For tube diameter
Other
Inlet from the rear
No
For Ex-zone gas
None
Connectable
Yes
Type of housing feed-through
Preembossing
For Ex-zone dust
None
Cover model
Blind cover
Castable
No
Casting compound included
No
Transparent cover
No
Degree of protection NEMA
-
Mounting in the soil
No
Mounting under water
No
Outgoing connections with connectors for plug-in building installation
-
Number of cable glands included
-
Brands
OBO
Technical Sheet
