Tube suspens.set 0,5m GuideLed DXC 10022
Emergency
Tube suspens.set 0,5m GuideLed DXC 10022
Manufacturer Ref:
40071355489
Nortécnica Ref:
EAN:
4012539357209
Description
Technical Information
Attributes
Mounting method
Pendant
Protection class according to IEC 61140
II
Colour
-
Largura
121
Diâmetro externo
-
Function
Escape route signage
Height
30
Lamp holder
None
Secção transversal do condutor
2.5
Connection type
Plug-in connection
Housing colour
Grey
Voltage type
DC
Type of accessoryspare part
-
EF000233
EV010184
Type of control gear
LED operating device voltage-controlled
With remote control
No
Diâmetro
-
Largura para embutir
-
Built-in diameter
-
Suitable for labelling type
Acrylic plate
Type of indicator
Single/double-sided
Número de polos
2
Comprimento
221
Alturaprofundidade
30
Housing material
Plastic
Material
-
Lamp type
-
Number of lighting heads
-
Comprimento para embutir
-
Material cover
Without cover
Impact strength
IK03
Battery technology
-
Nominal voltage
220
240
Degree of protection IP
IP20
With light source
No
Transparent
-
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Adequado para número de lâmpadas
-
With remote switch connection
No
EF008091
EV010144
Recognition distance
20
Nominal current
-
Colour temperature
-
Potência máx. do sistema
3.1
EF009349
-
Constant light output CLO
No
With pictogram
No
Type of wiring
Suitable for loop-through wiring
Vida útil nominal L70B50 a 25 C
-
Luminous flux in standby mode
-
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
-20
40
Light distributor
Diffuser lens/optic/panel
RAL-number housing
7035
Nominal operation time
-
Accessory
-
Spare part
-
Número max. de luminárias por disjuntor C16
-
Número max. de luminárias por disjuntor B16
-
Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
-
Depreciação do fluxo luminoso; vida útil média de 100 000 h; temp 25 C tq
-
Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
-
Taxa de falha, vida operacional média 100 000 h, temperatura 25 C tq
-
Valor estroboscópico Pst LM
-
Valor de efeito estroboscópico SVM
-
Exchangeable control gear
No
Energy efficiency class of the light source according to EU regulation 20192015
A
Suitable for standby switching
No
Suitable for continuous circuit
No
Alturaprofundidade para embutir
-
Fator de potência
0.62
