BDP102 LED70740 DRW PCC GR D9 62P
Exterior
BDP102 LED70740 DRW PCC GR D9 62P
Manufacturer Ref:
34709600
Nortécnica Ref:
EAN:
8718696347096
Description
Technical Information
Attributes
Mounting method
Post top
EF000004
I
Width
570
Lamp holder
Other
Conductor cross section
1.5
Connection type
Screwed terminal
Housing colour
Grey
Surface protection
Powder coating
Voltage type
AC
Suitable for lamp power
-
-
Type of control gear
LED operating device current-controlled
Colour rendering index CRI
70-79
Cable length
-
Diameter
570
With light sensor
No
Number of poles
3
Length
570
Heightdepth
317
Housing material
Aluminium
Lamp type
LED exchangeable
Material cover
Plastic transparent
Impact strength
IK10
With connection cable
No
Nominal voltage
220
240
Degree of protection IP
IP66
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Suitable for number of light sources
-
With control gear
Yes
Adjustable optics
No
Suitable for spigot size
62
62
Nominal current
180
220
Colour temperature
4000
4000
Max. system power
45.5
EF009349
4900
Colour of light
White
Remote control
Group control
With radio control
No
With light regulation program control
No
Constant light output CLO
No
IFTTT support available
No
Type of wiring
Ending
Rated lifetime L70B50 at 25 C
-
Colour consistency McAdam ellipse
SDCM5
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
25
25
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
Yes
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
No
Light distributor
Focal lens
EF012172
108
Dimming DSI
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. number of luminaires per miniature circuit breaker C16 MCB
17
Max. number of luminaires per miniature circuit breaker B16 MCB
10
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
97
Lumen maintenance at median useful life of 100,000 h at 25 C ambient tq
94
Failure rate at median useful life of 50,000 h at 25 C ambient tq
5
Failure rate at median useful life of 100,000 h at 25 C ambient tq
10
Exchangeable control gear
Yes
Type of connection for sensorcommunication module
-
Energy efficiency class of the light source according to EU regulation 20192015
-
Power factor
0.96
Brands
PHILIPS
