Exterior

STREETLIGHT AREA MEDIUM RV20ST 65W 727 RV20ST GY

Manufacturer Ref: 4099854030437
Nortécnica Ref:
EAN: 4099854030437
Description

STREETLIGHT AREA MEDIUM RV20ST 65W 727 RV20ST GY

Technical Information
Attributes
Mounting method
Post top
EF000004
I
Width
193.00
Lamp holder
None
Conductor cross section
-
Connection type
Other
Housing colour
Grey
Surface protection
Powder coating
Voltage type
AC
Suitable for lamp power
-
Type of control gear
-
Colour rendering index CRI
70-79
Cable length
0.5
Diameter
-
With light sensor
No
Number of poles
3
Length
513.00
Heightdepth
73.00
Housing material
Aluminium
Lamp type
LED not exchangeable
Material cover
Plastic, opal
Impact strength
IK08
With connection cable
Yes
Nominal voltage
100
240
Degree of protection IP
IP66
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Suitable for number of light sources
0
With control gear
Yes
Adjustable optics
No
Suitable for spigot size
60
60
Nominal current
295.000
295.000
Colour temperature
2700
2700
Max. system power
65.00
EF009349
8450
Colour of light
White
Remote control
None
With radio control
No
With light regulation program control
No
Constant light output CLO
No
IFTTT support available
Yes
Type of wiring
Ending
Rated lifetime L70B50 at 25 C
100000
Colour consistency McAdam ellipse
-
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
-30
+50
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
Yes
Light distributor
Focal lens
EF012172
130
Dimming DSI
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. number of luminaires per miniature circuit breaker C16 MCB
88
Max. number of luminaires per miniature circuit breaker B16 MCB
40
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 100,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
-
Failure rate at median useful life of 100,000 h at 25 C ambient tq
-
Exchangeable control gear
Yes
Type of connection for sensorcommunication module
-
Energy efficiency class of the light source according to EU regulation 20192015
D
Power factor
0.90
Brands
LEDVANCE
