VGP283 80 4S740 48V III DM10 4860S
Exterior
VGP283 80 4S740 48V III DM10 4860S
Manufacturer Ref:
62373600
Nortécnica Ref:
EAN:
8719514623736
Description
Technical Information
Attributes
Mounting method
Side entry
Protection class according to IEC 61140
III
Largura
340
Lamp holder
Other
Secção transversal do condutor
0.75
Connection type
Push-in clamp
Housing colour
Grey
Surface protection
Powder coating
Voltage type
DC
Suitable for lamp power
-
-
Type of control gear
LED operating device current-controlled
Índice de restituição de cor CRI
70-79
Cable length
-
Diâmetro
-
With light sensor
No
Número de polos
2
Comprimento
626
Alturaprofundidade
95
Housing material
Aluminium
Lamp type
LED exchangeable
Material cover
Glass transparent
Impact strength
IK08
With connection cable
No
Nominal voltage
48
48
Degree of protection IP
IP66
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Adequado para número de lâmpadas
-
With control gear
No
Adjustable optics
No
Suitable for spigot size
48
60
Nominal current
-
Colour temperature
4000
4000
Potência máx. do sistema
99
EF009349
-
Colour of light
White
Remote control
None
With radio control
No
With light regulation program control
No
Constant light output CLO
No
IFTTT support available
No
Type of wiring
Ending
Vida útil nominal L70B50 a 25 C
-
Colour consistency McAdam ellipse
SDCM5
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
-40
50
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Regulação LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Regulação por redução da onda sinusoidal
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
Yes
Light distributor
Diffuser lens/optic/panel
EF012172
-
Dimming DSI
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Número max. de luminárias por disjuntor C16
0
Número max. de luminárias por disjuntor B16
0
Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
-
Depreciação do fluxo luminoso; vida útil média de 100 000 h; temp 25 C tq
10
Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
10
Taxa de falha, vida operacional média 100 000 h, temperatura 25 C tq
-
Exchangeable control gear
No
Type of connection for sensorcommunication module
-
Energy efficiency class of the light source according to EU regulation 20192015
-
Fator de potência
-
Brands
Signify
