BGP236 LED360-4S740 DSM11 D9 MIO-CIO MB
Industry
BGP236 LED360-4S740 DSM11 D9 MIO-CIO MB
Manufacturer Ref:
48296100
Nortécnica Ref:
EAN:
8718699482961
Description
Technical Information
Attributes
Protection class according to IEC 61140
I
Largura
485.5
Lamp holder
Other
Secção transversal do condutor
1.5
Connection type
Push-in clamp
Voltage type
AC
Suitable for lamp power
-
-
Type of control gear
LED operating device current-controlled
Índice de restituição de cor CRI
70-79
Diâmetro
-
Número de polos
5
Comprimento
727
Alturaprofundidade
89.5
Housing material
Aluminium
Lamp type
LED exchangeable
Suitable for light line configuration
Yes
Impact strength
IK09
Nominal voltage
220
240
Degree of protection IP
IP66
With light source
Yes
Adequado para número de lâmpadas
-
With control gear
Yes
Nominal current
430
430
Colour temperature
4000
4000
Potência máx. do sistema
210
EF009349
29880
Colour of light
White
Constant light output CLO
No
Type of wiring
Loop-through wiring included
Vida útil nominal L70B50 a 25 C
-
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
Yes
Dimming DMX
No
Dimming potentiometer integrated
No
Regulação LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Regulação por redução da onda sinusoidal
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
No
Light distributor
Refractor lens
EF012172
149
Dimming DSI
No
Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
-
Depreciação do fluxo luminoso; vida útil média de 100 000 h; temp 25 C tq
97
Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
-
Taxa de falha, vida operacional média 100 000 h, temperatura 25 C tq
10
Exchangeable control gear
Yes
Energy efficiency class of the light source according to EU regulation 20192015
D
Fator de potência
0.99
Brands
Signify
