BY021P G2 LED205S840 PSU WB GR
Industry
BY021P G2 LED205S840 PSU WB GR
Manufacturer Ref:
52404000
Nortécnica Ref:
EAN:
8719514524040
Description
Technical Information
Attributes
Mounting method
EV006028
EF000004
I
Width
-
Outer diameter
355
Reflector
None
Lamp holder
None
Conductor cross section
1
Connection type
Push-in clamp
Housing colour
Grey
Voltage type
AC
Suitable for lamp power
137
168
Type of control gear
LED operating device current-controlled
Colour rendering index CRI
80-89
EF001263
No
Number of poles
3
Length
-
Heightdepth
93
Housing material
Aluminium
Lamp type
LED not exchangeable
Reflector colour
Other
Suitable for emergency lighting
No
Light distribution
Symmetric
Material reflector
Other
Impact strength
IK06
Nominal voltage
220
240
Emergency power supply integrated
No
Degree of protection IP
IP65
With protective cover
Yes
With light source
No
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Suitable for number of light sources
1
With control gear
Yes
Beam angle
80 - Extreme wide beam
Nominal current
700
860
Colour temperature
4000
4000
Max. system power
168
EF009349
20500
Colour of light
White
Constant light output CLO
No
Type of wiring
Ending
Rated lifetime L70B50 at 25 C
35000
Colour consistency McAdam ellipse
SDCM5
EF011947
0.2
Photobiological safety according to EN 62471
RG0
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
35
35
Filament test according to IEC 60695-2-11
650 C - 30 s
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
Yes
Light distributor
Refractor lens
EF012172
122
Dimming DSI
No
Suitable for auxiliary lamp
No
Operation by Bluetooth
No
Max. number of luminaires per miniature circuit breaker C16 MCB
8
Max. number of luminaires per miniature circuit breaker B16 MCB
6
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
70
Lumen maintenance at median useful life of 100,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
7.5
Failure rate at median useful life of 100,000 h at 25 C ambient tq
-
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
No
Energy efficiency class of the light source according to EU regulation 20192015
E
Power factor
0.9
Meets min. EIA lifetime criterion L90 at 50,000 hours at tq 25 C
No
Brands
PHILIPS
