RLF 2503636 N 26-2 M - 1.5H
Industry
RLF 2503636 N 26-2 M - 1.5H
Manufacturer Ref:
12283236202
Nortécnica Ref:
EAN:
4250217400940
Description
Technical Information
Attributes
Mounting method
Wall-/ceiling mounting
Protection class according to IEC 61140
I
Largura
302
Diâmetro externo
-
Lamp holder
G13
Secção transversal do condutor
2.5
Connection type
Screwed terminal
Voltage type
AC
Suitable for lamp power
36
36
Type of control gear
Electronic ballast
Adjustable
Yes
Número de polos
6
Comprimento
1.312
Alturaprofundidade
130
Housing material
-
Lamp type
Fluorescent lamp
Material cover
Glass transparent
Impact strength
IK10
Nominal voltage
110
254
Degree of protection IP
IP65
For Ex-zone gas
1, 2
With light source
No
Adequado para número de lâmpadas
-
With control gear
Yes
Beam angle
41-80° - Wide beam
For Ex-zone dust
21, 22
Nominal current
-
Colour temperature
-
Potência máx. do sistema
-
EF009349
6.7
Colour of light
-
Constant light output CLO
No
Type of wiring
Loop-through wiring included
Vida útil nominal L70B50 a 25 C
-
Degree of protection NEMA
Other
Rated ambient temperature according to IEC 62722-2-1
-
Light distributor
Reflector
EF012172
-
Número max. de luminárias por disjuntor C16
-
Número max. de luminárias por disjuntor B16
-
Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
-
Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
-
Exchangeable control gear
No
Energy efficiency class of the light source according to EU regulation 20192015
-
Fator de potência
0.95
