TruSys FLEX VERY WIDE 70W 840 VW CL WT DALI
Industry
TruSys FLEX VERY WIDE 70W 840 VW CL WT DALI
Manufacturer Ref:
4058075771055
Nortécnica Ref:
EAN:
4058075771055
Description
Technical Information
Attributes
EF000004
I
Width
77.70
Reflector
None
Lamp holder
None
Conductor cross section
-
Connection type
Other
Housing colour
White
Voltage type
AC/DC
Suitable for lamp power
-
Type of control gear
Electronic ballast
Colour rendering index CRI
80-89
Number of poles
3
Length
1500.00
Heightdepth
39.40
Housing material
-
Lamp type
LED not exchangeable
Suitable for emergency lighting
No
Light outlet
Direct
Light distribution
Symmetric
Nominal voltage
220
240
Emergency power supply integrated
No
Degree of protection IP
IP40
With light source
Yes
Suitable for number of light sources
0
With control gear
Yes
Beam angle
-
Nominal current
320.000
320.000
Colour temperature
4000
4000
Max. system power
70.00
EF009349
12100
Colour of light
White
Constant light output CLO
No
Type of wiring
Suitable for loop-through wiring
Rated lifetime L70B50 at 25 C
100000
EF011871
76000
Colour consistency McAdam ellipse
SDCM3
EF011947
-
Rated ambient temperature according to IEC 62722-2-1
-25
+35
Filament test according to IEC 60695-2-11
-
Dimming 0-10 V
No
Dimming 1-10 V
Yes
Dimming DALI
Yes
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
No
Light distributor
Focal lens
EF012172
175
Dimming DSI
No
Operation by Bluetooth
No
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 100,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
-
Failure rate at median useful life of 100,000 h at 25 C ambient tq
-
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
Yes
Compatible with Casambi
-
Energy efficiency class of the light source according to EU regulation 20192015
-
Power factor
0.95
Brands
LEDVANCE
Technical Sheet
