BCP333 LED81740 I PRM
Interior
BCP333 LED81740 I PRM
Manufacturer Ref:
99766600
Nortécnica Ref:
EAN:
8718696997666
Description
Technical Information
Attributes
Protection class according to IEC 61140
I
Largura
346
Diâmetro externo
-
Lamp holder
Other
Secção transversal do condutor
0.75
Connection type
Screwed terminal
Housing colour
White
Voltage type
AC
With movement sensor
No
Suitable for lamp power
-
-
Type of grid
None
Type of control gear
LED operating device current-controlled
Índice de restituição de cor CRI
70-79
Suitable for wall mounting
No
Largura para embutir
346
Built-in diameter
-
With light sensor
No
Suitable for suspended mounting
No
Intensidade luminosa
2703.3
Número de polos
3
Comprimento
346
Alturaprofundidade
139
Housing material
Aluminium
Lamp type
LED not exchangeable
Comprimento para embutir
346
Suitable for light line configuration
Yes
Suitable for emergency lighting
No
Light outlet
Direct
Light distribution
Symmetric
Material cover
Plastic, structured
Impact strength
IK08
Nominal voltage
220
240
EF005138
No
Degree of protection IP
EV006422
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Covering of the luminaire with thermally insulating material possible
Yes
Adequado para número de lâmpadas
2
Suitable for built-in mounting
Yes
With control gear
Yes
Suitable for workplace according to EN 12464-1
No
Suitable for surface mounting
Yes
Beam angle
21-40° - Medium beam
Nominal current
350
440
Colour temperature
4000
4000
Potência máx. do sistema
48
EF009349
7462
Colour of light
White
With air slots
No
Constant light output CLO
No
IFTTT support available
No
Type of wiring
Ending
Vida útil nominal L70B50 a 25 C
-
Colour consistency McAdam ellipse
SDCM5
EF011947
0.1132
Photobiological safety according to EN 62471
RG0
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
25
25
Filament test according to IEC 60695-2-11
850 °C - 30 s
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Regulação LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Regulação por redução da onda sinusoidal
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
Yes
Light distributor
Diffuser lens/optic/panel
EF012172
155
Dimming DSI
No
Fator de brilho unificado UGR
-
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Número max. de luminárias por disjuntor C16
18
Número max. de luminárias por disjuntor B16
11
Depreciação do fluxo luminoso; vida útil média de 35 000 h; temp 25 C tq
99
Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
98
Lumen maintenance at median useful life of 75,000 h at 25 C ambient tq
97
Taxa de falha, vida operacional média 35 000 h, temperatura 25 C tq
35
Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
5
Failure rate at median useful life of 75,000 h at 25 C ambient tq
75
Dimming DALI-2
No
Valor estroboscópico Pst LM
0.45
Valor de efeito estroboscópico SVM
0.08
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
No
Compatible with Casambi
No
Energy efficiency class of the light source according to EU regulation 20192015
-
Suitable for ceiling mounting
Yes
Alturaprofundidade para embutir
0
Surface protection housing
Untreated
Fator de potência
0.98
Meets min. EIA lifetime criterion L90 at 50,000 hours at tq 25 C
Yes
Brands
Signify
Technical Sheet
