DAMP PROOF 1200 32W 830 IP65 GY
Interior
DAMP PROOF 1200 32W 830 IP65 GY
Manufacturer Ref:
4058075541085
Nortécnica Ref:
EAN:
4058075541085
Description
Technical Information
Attributes
EF000004
I
Width
82.00
Outer diameter
-
Lamp holder
-
Conductor cross section
-
Connection type
Push-in clamp
Housing colour
Grey
Voltage type
AC
With movement sensor
No
Suitable for lamp power
-
Type of grid
Other
Type of control gear
Electronic ballast
Colour rendering index CRI
80-89
Suitable for wall mounting
Yes
Built-in width
-
Built-in diameter
-
With light sensor
No
Suitable for suspended mounting
Yes
EF001357
-
Number of poles
3
Length
1200.00
Heightdepth
68.00
Housing material
Plastic
Lamp type
LED not exchangeable
Built-in length
-
Suitable for light line configuration
No
Suitable for emergency lighting
No
Light outlet
Direct
Light distribution
-
Material cover
Plastic, opal
Impact strength
IK08
Nominal voltage
220
240
Emergency power supply integrated
No
Degree of protection IP
EV006421
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
-
Covering of the luminaire with thermally insulating material possible
No
Suitable for number of light sources
0
Suitable for built-in mounting
No
With control gear
Yes
Suitable for workplace according to EN 12464-1
No
Suitable for surface mounting
Yes
Beam angle
-
Nominal current
280.000
280.000
Colour temperature
3000
3000
Max. system power
32.00
EF009349
4000
Colour of light
White
With air slots
No
Constant light output CLO
-
IFTTT support available
Yes
Type of wiring
Suitable for loop-through wiring
Rated lifetime L70B50 at 25 C
70000
Colour consistency McAdam ellipse
SDCM4
EF011947
-
Photobiological safety according to EN 62471
RG0
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
-25
+40
Filament test according to IEC 60695-2-11
-
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
Yes
Light distributor
Diffuser lens/optic/panel
EF012172
125
Dimming DSI
No
Unified Glare Ratio UGR
-
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. number of luminaires per miniature circuit breaker C16 MCB
39
Max. number of luminaires per miniature circuit breaker B16 MCB
27
Lumen maintenance at median useful life of 35,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 75,000 h at 25 C ambient tq
-
Failure rate at median useful life of 35,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
-
Failure rate at median useful life of 75,000 h at 25 C ambient tq
-
Dimming DALI-2
No
Flickering value Pst LM
-
Stroboscope effect value SVM
-
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
No
Compatible with Casambi
-
Energy efficiency class of the light source according to EU regulation 20192015
-
Suitable for ceiling mounting
Yes
Built-in heightdepth
-
Surface protection housing
Untreated
Power factor
0.90
Brands
LEDVANCE
