SPOT AIR ADJUST 4W 930 DIM IP23 BK
Interior
SPOT AIR ADJUST 4W 930 DIM IP23 BK
Manufacturer Ref:
4099854000089
Nortécnica Ref:
EAN:
4099854000089
Description
Technical Information
Attributes
EF000004
II
Width
81.00
Outer diameter
81.00
Reflector
None
Lamp holder
None
Conductor cross section
-
Connection type
-
Housing colour
Black
Surface protection
Powder coating
Voltage type
AC
With movement sensor
No
Suitable for lamp power
-
Type of control gear
LED operating device current-controlled
Colour rendering index CRI
90-100
Suitable for wall mounting
No
Built-in width
68
With light sensor
No
Suitable for suspended mounting
No
EF001357
-
Number of poles
2
Length
81.00
Heightdepth
34.00
Housing material
Aluminium
Lamp type
LED not exchangeable
Reflector colour
-
Built-in length
68
Light outlet
Direct
Light distribution
Symmetric
Material cover
Plastic, transparent
Impact strength
IK03
Nominal voltage
220
240
Emergency power supply integrated
No
Degree of protection IP
EV006407
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Covering of the luminaire with thermally insulating material possible
No
Suitable for number of light sources
0
Suitable for built-in mounting
Yes
With control gear
Yes
Suitable for workplace according to EN 12464-1
No
Suitable for surface mounting
Yes
Beam angle
-
Connectable conductor cross section
-
Surface brushed
No
Nominal current
20.000
20.000
Colour temperature
3000
3000
Max. system power
4.00
EF009349
320
Colour of light
White
Adjustability
Swivelling
Suitable for traverse mounting
No
Suitable for pedestalfloor mounting
No
Suitable for light-track mounting
No
Suitable for clamp-mounting
No
Constant light output CLO
No
IFTTT support available
Yes
EF011587
320
320
Type of wiring
Suitable for loop-through wiring
Rated lifetime L70B50 at 25 C
50000
Colour consistency McAdam ellipse
SDCM3
EF011947
-
Photobiological safety according to EN 62471
RG1
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
-20
+40
Filament test according to IEC 60695-2-11
-
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
Yes
Dimming phase cut-on leading edge
Yes
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
No
Light distributor
Focal lens
EF012172
80
Suitable for low voltage cable system
No
Dimming DSI
No
Unified Glare Ratio UGR
-
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. number of luminaires per miniature circuit breaker C16 MCB
480
Max. number of luminaires per miniature circuit breaker B16 MCB
376
Lumen maintenance at median useful life of 35,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 100,000 h at 25 C ambient tq
-
Failure rate at median useful life of 35,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
-
Failure rate at median useful life of 100,000 h at 25 C ambient tq
-
Dimming DALI-2
No
Flickering value Pst LM
-
Stroboscope effect value SVM
-
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
Yes
Built-in diameter
68
68
Energy efficiency class of the light source according to EU regulation 20192015
-
Suitable for ceiling mounting
Yes
Built-in heightdepth
35.0
Power factor
0.80
Brands
LEDVANCE
