WL055V LED6S830 PSU WH
Interior
WL055V LED6S830 PSU WH
Manufacturer Ref:
34941199
Nortécnica Ref:
EAN:
8710163349411
Description
Technical Information
Attributes
EF000004
II
Width
150
Outer diameter
-
Lamp holder
Other
Conductor cross section
1
Connection type
Other
Housing colour
White
Voltage type
AC
With movement sensor
No
Suitable for lamp power
-
-
Type of grid
None
Type of control gear
LED operating device current-controlled
Colour rendering index CRI
80-89
Suitable for wall mounting
Yes
Built-in width
-
Built-in diameter
-
With light sensor
No
Suitable for suspended mounting
No
EF001357
-
Number of poles
2
Length
374
Heightdepth
82
Housing material
Plastic
Lamp type
LED not exchangeable
Built-in length
-
Suitable for light line configuration
No
Suitable for emergency lighting
No
Light outlet
Direct
Light distribution
Symmetric
Material cover
Plastic opal
Impact strength
IK08
Nominal voltage
220
240
Emergency power supply integrated
No
Degree of protection IP
EV006421
With light source
Yes
Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
No
Covering of the luminaire with thermally insulating material possible
No
Suitable for number of light sources
-
Suitable for built-in mounting
No
With control gear
Yes
Suitable for workplace according to EN 12464-1
No
Suitable for surface mounting
No
Beam angle
80 - Extreme wide beam
Nominal current
30
30
Colour temperature
3000
3000
Max. system power
6
EF009349
600
Colour of light
White
With air slots
No
Constant light output CLO
No
IFTTT support available
No
Type of wiring
Suitable for loop-through wiring
Rated lifetime L70B50 at 25 C
30000
Colour consistency McAdam ellipse
SDCM5
EF011947
20
Photobiological safety according to EN 62471
RG0
Degree of protection NEMA
-
Rated ambient temperature according to IEC 62722-2-1
25
25
Filament test according to IEC 60695-2-11
850 C - 30 s
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming potentiometer integrated
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off trailing edge
No
Dimming phase cut-on leading edge
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
EF012169
Yes
Light distributor
Other
EF012172
100
Dimming DSI
No
Unified Glare Ratio UGR
25
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Max. number of luminaires per miniature circuit breaker C16 MCB
134
Max. number of luminaires per miniature circuit breaker B16 MCB
79
Lumen maintenance at median useful life of 35,000 h at 25 C ambient tq
-
Lumen maintenance at median useful life of 50,000 h at 25 C ambient tq
65
Lumen maintenance at median useful life of 75,000 h at 25 C ambient tq
-
Failure rate at median useful life of 35,000 h at 25 C ambient tq
-
Failure rate at median useful life of 50,000 h at 25 C ambient tq
7.5
Failure rate at median useful life of 75,000 h at 25 C ambient tq
-
Dimming DALI-2
No
Flickering value Pst LM
1
Stroboscope effect value SVM
1.6
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Exchangeable control gear
No
Compatible with Casambi
No
Energy efficiency class of the light source according to EU regulation 20192015
D
Suitable for ceiling mounting
Yes
Built-in heightdepth
-
Surface protection housing
Untreated
Power factor
0.82
Meets min. EIA lifetime criterion L90 at 50,000 hours at tq 25 C
No
Brands
PHILIPS
