Caminho de cabos em varão com união de encaixe rápido com 55 mm de altura lateral.
Cable Routes
Caminho de cabos em varão GRM 55x200x3000 Aço inoxidável A4 1.4401 brilhante, pós-tratamento aço inoxidável
Nortécnica Ref:
EAN:
4012195166061
Description
Technical Information
Attributes
Colour
Stainless steel
Width
200
Model
Integrated connector
Height
55
Type of connection
-
RAL-number
-
Surface protection
Untreated
EF000141
EV008273
Weight
0.99
Material quality
Stainless steel 316 (1.4401)
Length
3000
Working temperature
-
-
Material
Stainless steel
Integrated partition
None
Usable cross section
8700
Profile shape
U-shape
Working length
-
Suitable for circuit integrity
Yes
Load test type according to IEC 61537
Type II
Diameter longitudinal wire
3.9
Possible support spacing
1
2.5
Safe working load according to IEC 61537 with support spacing 0.5 m
-
Safe working load according to IEC 61537 with support spacing 1.0 m
350
Safe working load according to IEC 61537 with support spacing 1.5 m
200
Safe working load according to IEC 61537 with support spacing 2.0 m
100
Safe working load according to IEC 61537 with support spacing 2.5 m
100
Safe working load according to IEC 61537 with support spacing 3.0 m
-
Safe working load according to IEC 61537 with support spacing 4.0 m
-
Safe working load according to IEC 61537 with support spacing 5.0 m
-
Safe working load according to IEC 61537 with support spacing 6.0 m
-
Safe working load according to IEC 61537 with support spacing 7.0 m
-
Safe working load according to IEC 61537 with support spacing 8.0 m
-
Safe working load according to IEC 61537 with support spacing 10.0 m
-
Diameter transverse wire
3.9
Safe working load according to IEC 61537 with support spacing 9.0 m
-
Safe working load according to IEC 61537 with support spacing 11.0 m
-
Safe working load according to IEC 61537 with support spacing 12.0 m
-
Brands
OBO
Long Description
Caminho de cabos em varão com união de encaixe rápido com 55 mm de altura lateral.
