    LEDPanelS-E4 Sq595-32W-840
    OPPLE
    LEDPanelS-E4 Sq595-32W-840
    LEDPanelS-E4 Sq595-32W-840
    LEDPanelS-E4 Sq595-32W-840
    LEDPanelS-E4 Sq595-32W-840
    LEDPanelS-E4 Sq595-32W-840
    LEDPanelS-E4 Sq595-32W-840
    LEDPanelS-E4 Sq595-32W-840
    1234567

    Interior

    LEDPanelS-E4 Sq595-32W-840

    Nortécnica Ref: 68542003099800
    EAN: 6941497771575
    Login to see prices and stocks

    Description

    Suitable for recessed and suspended applications. Recessed ceiling frame and surface module kit available as accessory.

    Technical Information

    Attributes
    Protection class according to IEC 61140
    II
    Largura
    595
    Diâmetro externo
    -
    Lamp holder
    -
    Secção transversal do condutor
    -
    Connection type
    Free conductor end
    Housing colour
    White
    Dimmable
    No
    Voltage type
    AC/DC
    With movement sensor
    No
    Suitable for lamp power
    -
    Type of grid
    None
    Type of control gear
    LED operating device current-controlled
    Índice de restituição de cor CRI
    80-89
    Suitable for wall mounting
    No
    Largura para embutir
    -
    Diâmetro para embutir
    -
    With switch
    No
    With light sensor
    No
    Suitable for suspended mounting
    Yes
    Intensidade luminosa
    -
    Número de polos
    -
    Comprimento
    595
    Alturaprofundidade
    35
    Housing material
    Aluminium
    Lamp type
    LED not exchangeable
    With presence detector
    No
    Degree of protection IP front side
    IP20
    Comprimento para embutir
    -
    Suitable for light line configuration
    No
    Suitable for emergency lighting
    No
    Light outlet
    Direct
    Light distribution
    Symmetric
    Material cover
    Plastic, opal
    Impact strength
    IK03
    Nominal voltage
    220
    240
    Fonte de alimentação de emergência integrada
    No
    Degree of protection IP
    EV006405
    With light source
    Yes
    With mounting material
    No
    Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
    No
    Covering of the luminaire with thermally insulating material possible
    No
    Adequado para número de lâmpadas
    -
    Suitable for built-in mounting
    Yes
    With control gear
    Yes
    Suitable for workplace according to EN 12464-1
    -
    Suitable for surface mounting
    No
    Beam angle
    > 80° - Extreme wide beam
    Connectable conductor cross section
    0.75
    1.5
    Fluxo luminoso em funcionamento de emergência
    -
    Nominal current
    790
    790
    Colour temperature
    4000
    4000
    Potência máx. do sistema
    32
    EF009349
    4100
    Colour of light
    White
    With air slots
    No
    Suitable for clamp-mounting
    No
    Constant light output CLO
    No
    IFTTT support available
    No
    Type of wiring
    Ending
    Vida útil nominal L70B50 a 25 C
    60000
    Colour consistency McAdam ellipse
    SDCM3
    EF011947
    -
    Photobiological safety according to EN 62471
    RG0
    Degree of protection NEMA
    -
    Rated ambient temperature according to IEC 62722-2-1
    -10
    45
    Filament test according to IEC 60695-2-11
    650 °C - 30 s
    Dimming 0-10 V
    No
    Dimming 1-10 V
    No
    Dimming DALI
    No
    Dimming DMX
    No
    Dimming potentiometer integrated
    No
    Regulação LineSwitch
    No
    Dimming manufacturer's proprietary system
    No
    Dimming mains voltage modulation
    No
    Dimming phase cut-off trailing edge
    No
    Dimming phase cut-on leading edge
    No
    Dimming programmable
    No
    Dimming RF
    No
    Regulação por redução da onda sinusoidal
    No
    Dimming Touch and Dim
    No
    Dimming Zigbee
    No
    Dimming with push-button
    No
    EF012169
    Yes
    Light distributor
    Diffuser lens/optic/panel
    Rendimento da luminária
    130
    Dimming DSI
    No
    Fator de brilho unificado UGR
    22
    Operation by Bluetooth
    No
    Compatible with Apple HomeKit
    No
    Compatible with Google Assistant
    No
    Compatible with Amazon Alexa
    No
    Número max. de luminárias por disjuntor C16
    30
    Número max. de luminárias por disjuntor B16
    12
    Depreciação do fluxo luminoso; vida útil média de 35 000 h; temp 25 C tq
    -
    Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
    -
    Depreciação do fluxo luminoso; vida útil média de 75 000 h; temp 25 C tq
    -
    Taxa de falha, vida operacional média 35 000 h, temperatura 25 C tq
    -
    Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
    -
    Taxa de falha, vida operacional média 75 000 h, temperatura 25 C tq
    -
    Dimming DALI-2
    No
    Valor estroboscópico Pst LM
    -
    Valor de efeito estroboscópico SVM
    -
    Colour of light adjustable
    No
    Luminous flux adjustable
    No
    Beam angle adjustable
    No
    Exchangeable control gear
    Yes
    Compatible with Casambi
    No
    Energy efficiency class of the light source according to EU regulation 20192015
    D
    Intensidade luminosa
    -
    Degree of protection IP, rear side
    IP20
    Movement sensorpresence detector technology
    -
    Luminaire efficacy
    130
    130
    Rated luminous flux according to IEC 62722-2- 1
    4100
    4100
    Emergency power supply system
    None
    Consumo de energia em modo de emergência
    -
    Emergency function monitoring system
    None
    Containing product according to 20192020EU
    Yes
    Altura da gaveta
    -
    Número máximo de luminárias por disjuntor C10 MCB
    18
    Suitable for ceiling mounting
    Yes
    EF023518
    -
    Surface protection housing
    -
    Fator de potência
    0.9
    Ball-proof according to DIN 18032-3
    No
    Meets min. EIA lifetime criterion L90 at 50,000 hours at tq 25 C
    -
