    LL234X 90S840 2x PSU WB 5x1.5
    PHILIPS
    LL234X 90S840 2x PSU WB 5x1.5
    LL234X 90S840 2x PSU WB 5x1.5
    LL234X 90S840 2x PSU WB 5x1.5
    LL234X 90S840 2x PSU WB 5x1.5
    LL234X 90S840 2x PSU WB 5x1.5
    12345

    Industry

    LL234X 90S840 2x PSU WB 5x1.5

    Nortécnica Ref:
    EAN: 8719514617926
    Login to see prices and stocks

    Description

    L3400 mm, Aço, Branco, Branco sinalização (RAL9016), Unidade de fonte de alimentação (aceso/apagado), 9000 lm, 56 W, 161 lm/W, 4000 K, (0.38, 0.38) SDCM 3, UGR19, Feixe largo, Fosco, Policarbonato, IP20 | Proteção de dedos, IK02 | 0,2 J standard, Classe de segurança I, Unidade de ligação de 5 polos

    Technical Information

    Attributes
    Protection class according to IEC 61140
    I
    Largura
    80
    Reflector
    None
    Lamp holder
    None
    Secção transversal do condutor
    1.5
    Connection type
    Push-in clamp
    Housing colour
    White
    Voltage type
    AC
    Suitable for lamp power
    -
    -
    Type of control gear
    LED operating device current-controlled
    Índice de restituição de cor CRI
    80-89
    Número de polos
    5
    Comprimento
    3400
    Alturaprofundidade
    50
    Housing material
    Steel
    Lamp type
    LED not exchangeable
    Suitable for emergency lighting
    No
    Light outlet
    Direct
    Light distribution
    Symmetric
    Nominal voltage
    220
    240
    Fonte de alimentação de emergência integrada
    No
    Degree of protection IP
    IP20
    With light source
    Yes
    Adequado para número de lâmpadas
    6
    With control gear
    Yes
    Beam angle
    > 80° - Extreme wide beam
    Nominal current
    192
    192
    Colour temperature
    4000
    4000
    Potência máx. do sistema
    56
    EF009349
    9000
    Colour of light
    White
    Constant light output CLO
    No
    Type of wiring
    Loop-through wiring included
    Vida útil nominal L70B50 a 25 C
    -
    EF011871
    -
    Colour consistency McAdam ellipse
    SDCM3
    EF011947
    20
    Rated ambient temperature according to IEC 62722-2-1
    25
    25
    Filament test according to IEC 60695-2-11
    850 °C - 30 s
    Dimming 0-10 V
    No
    Dimming 1-10 V
    No
    Dimming DALI
    No
    Dimming DMX
    No
    Dimming potentiometer integrated
    No
    Regulação LineSwitch
    No
    Dimming manufacturer's proprietary system
    No
    Dimming mains voltage modulation
    No
    Dimming phase cut-off trailing edge
    No
    Dimming phase cut-on leading edge
    No
    Dimming programmable
    No
    Dimming RF
    No
    Regulação por redução da onda sinusoidal
    No
    Dimming Touch and Dim
    No
    Dimming Zigbee
    No
    Dimming with push-button
    No
    EF012169
    Yes
    Light distributor
    Diffuser lens/optic/panel
    Rendimento da luminária
    161
    Dimming DSI
    No
    Operation by Bluetooth
    No
    Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
    85
    Depreciação do fluxo luminoso; vida útil média de 100 000 h; temp 25 C tq
    75
    Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
    5
    Taxa de falha, vida operacional média 100 000 h, temperatura 25 C tq
    10
    Colour of light adjustable
    No
    Luminous flux adjustable
    No
    Beam angle adjustable
    No
    Exchangeable control gear
    Yes
    Compatible with Casambi
    No
    Energy efficiency class of the light source according to EU regulation 20192015
    D
    Fator de potência
    0.95
    Meets min. EIA lifetime criterion L90 at 50,000 hours at tq 25 C
    Yes
    Brands
    PHILIPS

    Technical Sheet

    Ficha Técnica 01
    Ficha Técnica 02
