    RS060B G2 LDNR LED5-36830 PSR II WH
    PHILIPS
    RS060B G2 LDNR LED5-36830 PSR II WH
    RS060B G2 LDNR LED5-36830 PSR II WH
    RS060B G2 LDNR LED5-36830 PSR II WH
    RS060B G2 LDNR LED5-36830 PSR II WH
    RS060B G2 LDNR LED5-36830 PSR II WH
    12345

    Interior

    RS060B G2 LDNR LED5-36830 PSR II WH

    Nortécnica Ref:
    EAN: 8719514331198
    Login to see prices and stocks

    Description

    Fixed, D68 mm, Metal-plástico, Branco, Regulação de unidade de fonte de alimentação, 500 lm, 6 W, 83 lm/W, 3000 K, (IEC3000K, 0.44, 0.403) 5SDCM, CRI80, Abertura de feixe 36°, Transparente, Policarbonato, IP20 | Proteção de dedos, IK03 | 0,3 J, Classe de segurança II, Conector de alimentação CA C13

    Technical Information

    Attributes
    Protection class according to IEC 61140
    II
    Largura
    -
    Diâmetro externo
    75
    Reflector
    Other
    Lamp holder
    Other
    Secção transversal do condutor
    0.75
    Connection type
    Insulation displacement connector
    Housing colour
    White
    Surface protection
    Other
    Voltage type
    AC
    With movement sensor
    No
    Suitable for lamp power
    5.4
    6.6
    Type of control gear
    LED operating device current-controlled
    Índice de restituição de cor CRI
    80-89
    Suitable for wall mounting
    No
    Largura para embutir
    -
    With light sensor
    No
    Suitable for suspended mounting
    No
    Intensidade luminosa
    1000
    Número de polos
    2
    Comprimento
    -
    Alturaprofundidade
    55
    Housing material
    Other
    Lamp type
    LED not exchangeable
    Reflector colour
    Silver
    Comprimento para embutir
    -
    Light outlet
    Direct
    Light distribution
    Symmetric
    Material cover
    Plastic, transparent
    Impact strength
    IK03
    Nominal voltage
    220
    240
    Fonte de alimentação de emergência integrada
    No
    Degree of protection IP
    EV006405
    With light source
    Yes
    Luminaire with limited surface temperature, sign "D according to EN 60598-2-24
    Yes
    Covering of the luminaire with thermally insulating material possible
    Yes
    Adequado para número de lâmpadas
    1
    Suitable for built-in mounting
    Yes
    With control gear
    Yes
    Suitable for workplace according to EN 12464-1
    Yes
    Suitable for surface mounting
    No
    Beam angle
    21-40° - Medium beam
    Connectable conductor cross section
    0.75
    1.5
    Surface brushed
    No
    Nominal current
    30
    30
    Colour temperature
    3000
    3000
    Potência máx. do sistema
    6
    EF009349
    500
    Colour of light
    White
    Adjustability
    Not adjustable
    Suitable for traverse mounting
    No
    Suitable for pedestalfloor mounting
    No
    Suitable for light-track mounting
    No
    Suitable for clamp-mounting
    No
    Constant light output CLO
    No
    IFTTT support available
    No
    Luminous flux
    500
    500
    Type of wiring
    Loop-through wiring included
    Vida útil nominal L70B50 a 25 C
    35000
    Colour consistency McAdam ellipse
    SDCM5
    EF011947
    0.21
    Photobiological safety according to EN 62471
    RG1
    Degree of protection NEMA
    -
    Rated ambient temperature according to IEC 62722-2-1
    -20
    40
    Filament test according to IEC 60695-2-11
    650 °C - 30 s
    Dimming 0-10 V
    No
    Dimming 1-10 V
    No
    Dimming DALI
    No
    Dimming DMX
    No
    Dimming potentiometer integrated
    No
    Regulação LineSwitch
    No
    Dimming manufacturer's proprietary system
    No
    Dimming mains voltage modulation
    No
    Dimming phase cut-off trailing edge
    Yes
    Dimming phase cut-on leading edge
    No
    Dimming programmable
    No
    Dimming RF
    No
    Regulação por redução da onda sinusoidal
    No
    Dimming Touch and Dim
    No
    Dimming Zigbee
    No
    Dimming with push-button
    No
    EF012169
    No
    Light distributor
    Reflector
    Rendimento da luminária
    83
    Suitable for low voltage cable system
    No
    Dimming DSI
    No
    Fator de brilho unificado UGR
    21
    Operation by Bluetooth
    No
    Compatible with Apple HomeKit
    No
    Compatible with Google Assistant
    No
    Compatible with Amazon Alexa
    No
    Número max. de luminárias por disjuntor C16
    100
    Número max. de luminárias por disjuntor B16
    100
    Depreciação do fluxo luminoso; vida útil média de 35 000 h; temp 25 C tq
    -
    Depreciação do fluxo luminoso; vida útil média de 50 000 h; temp 25 C tq
    -
    Depreciação do fluxo luminoso; vida útil média de 100 000 h; temp 25 C tq
    -
    Taxa de falha, vida operacional média 35 000 h, temperatura 25 C tq
    -
    Taxa de falha, vida operacional média 50 000 h, temperatura 25 C tq
    -
    Taxa de falha, vida operacional média 100 000 h, temperatura 25 C tq
    -
    Dimming DALI-2
    No
    Valor estroboscópico Pst LM
    0.1
    Valor de efeito estroboscópico SVM
    0.1
    Colour of light adjustable
    No
    Luminous flux adjustable
    Continuously variable
    Beam angle adjustable
    No
    Exchangeable control gear
    No
    Built-in diameter
    68
    68
    Energy efficiency class of the light source according to EU regulation 20192015
    F
    Suitable for ceiling mounting
    No
    EF023518
    53
    Fator de potência
    0.9
    Brands
    PHILIPS

    Technical Sheet

    Ficha Técnica 01
    Ficha Técnica 02
