Bloco dif dup saída 4P 63A sel 1A AC
Cutting and Protection Devices
Bloco dif dup saída 4P 63A sel 1A AC
Manufacturer Ref:
BSC863
Nortécnica Ref:
71BSC863
EAN:
3250611310181
Description
Technical Information
Attributes
Nominal current
63
Rated insulation voltage Ui
500
Number of poles
4
Delay adjustable
No
Max. delay time
300
Leakage current type
AC
Surge current capacity
-
Pollution degree
2
Rated fault current
1
1
Nominal voltage
230
400
Power loss
9
Frequency
50 Hz
Degree of protection IP
IP20
Connectable conductor cross section solid-core
-
Connectable conductor cross section multi-wired
-
With interlocking device
-
Ambient temperature during operating
-25
40
Rated fault current adjustable
No
Anti-nuisance tripping version
No
Rated impulse withstand voltage Uimp
4
Brands
Hager Sistemas Eléctricos Modulares SA
Technical Sheet
