ComPacT DISJUNTOR NSX160H 70kA CA 3P3D 160A 2,2
Cutting and Protection Devices
ComPacT DISJUNTOR NSX160H 70kA CA 3P3D 160A 2,2
Manufacturer Ref:
C16H32D160
Nortécnica Ref:
EAN:
3606481998620
Description
Technical Information
Attributes
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Rated permanent current Iu
160
With integrated under voltage release
No
Número de polos
3
Overload release current setting
57
160
Number of auxiliary contacts as change-over contact
0
Rated voltage
690
690
Potência dissipada
27.6
Degree of protection IP
IP40
Position of connection for main current circuit
Front side
Motor drive integrated
No
Type of electrical connection of main circuit
Screw connection
Type of control element
Wing knob
With switched-off indicator
Yes
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
70
Adjustment range short-term delayed short-circuit release
86
1600
Adjustment range undelayed short-circuit release
2400
2400
Suitable for DIN rail top hat rail mounting
No
Integrated earth fault protection
No
Motor drive optional
Yes
Device construction
Built-in device fixed built-in technique
DIN rail top hat rail mounting optional
Yes
Complete device with protection unit
Yes
Brands
Schneider
