ComPacT DISJUNTOR NSX250R 200kA CA 4P 250A 2,2
Cutting and Protection Devices
ComPacT DISJUNTOR NSX250R 200kA CA 4P 250A 2,2
Manufacturer Ref:
C25R42D250
Nortécnica Ref:
EAN:
3606482001213
Description
Technical Information
Attributes
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Rated permanent current Iu
250
With integrated under voltage release
No
Número de polos
4
Overload release current setting
225
250
Number of auxiliary contacts as change-over contact
0
Rated voltage
690
690
Potência dissipada
70.4
Degree of protection IP
IP40
Position of connection for main current circuit
Front side
Motor drive integrated
No
Type of electrical connection of main circuit
Screw connection
Type of control element
Wing knob
With switched-off indicator
Yes
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
200
Adjustment range short-term delayed short-circuit release
375
2500
Adjustment range undelayed short-circuit release
3000
3000
Suitable for DIN rail top hat rail mounting
No
Integrated earth fault protection
No
Motor drive optional
Yes
Device construction
Built-in device fixed built-in technique
DIN rail top hat rail mounting optional
Yes
Complete device with protection unit
Yes
Brands
Schneider
