M 281 UC FS C6 Miniature Circuit Breaker - 1P - C - 6 A
Cutting and Protection Devices
M 281 UC FS C6 Miniature Circuit Breaker - 1P - C - 6 A
Manufacturer Ref:
11864375
Nortécnica Ref:
EAN:
8012542557036
Description
Technical Information
Attributes
Voltage type
AC/DC
Built-in depth
68
Rated current
6
Rated voltage
-
Frequency
50
60
Release characteristic
C
Rated insulation voltage Ui
-
Current limiting class
3
Overvoltage category
3
Pollution degree
3
Largura em número de módulos
1
Explosion-proof
No
Power loss
-
Degree of protection IP
IP20
Number of protected poles
1
Concurrently switching neutral conductor
No
Connectable conductor cross section solid-core
1
35
Connectable conductor cross section multi-wired
1
25
Ambient temperature during operating
-25
55
Flush-mounted installation
No
Additional equipment possible
Yes
Number of poles total
1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
25
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
-
Rated impulse withstand voltage Uimp
5
Brands
ABB
