NS1250N 50kA 4P 1250A Fixo Manual 2.0E
Cutting and Protection Devices
NS1250N 50kA 4P 1250A Fixo Manual 2.0E
Manufacturer Ref:
C125N42EFM
Nortécnica Ref:
51C125N42EFM
EAN:
3606482098053
Description
Technical Information
Attributes
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Rated permanent current Iu
1250
With integrated under voltage release
No
Number of poles
4
Overload release current setting
500
1250
Number of auxiliary contacts as change-over contact
0
Rated voltage
690
690
Power loss
176
Degree of protection IP
IP40
Position of connection for main current circuit
Front side
Motor drive integrated
No
Type of electrical connection of main circuit
Screw connection
Type of control element
Wing knob
With switched-off indicator
Yes
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
50
Adjustment range short-term delayed short-circuit release
-
-
Adjustment range undelayed short-circuit release
750
12500
Suitable for DIN rail top hat rail mounting
No
Integrated earth fault protection
No
Motor drive optional
Yes
Device construction
Built-in device fixed built-in technique
DIN rail top hat rail mounting optional
No
Complete device with protection unit
Yes
Brands
Schneider
Technical Sheet
