TeSys GV4 - disjuntor magneto-térmico multifuncional - 3.5A 3P - term. olhal
Cutting and Protection Devices
TeSys GV4 - disjuntor magneto-térmico multifuncional - 3.5A 3P - term. olhal
Manufacturer Ref:
GV4PEM03N6
Nortécnica Ref:
EAN:
3606481386366
Description
Technical Information
Attributes
Width
81
Height
155
Depth
116
Rated operation power at AC-3, 400 V
1.5
With integrated auxiliary switch
No
Rated permanent current Iu
3.5
With integrated under voltage release
No
Number of poles
3
Rated operating voltage
690
690
Overload release current setting
1.4
3.5
Power loss
13.8
Degree of protection IP
IP40
With thermal overload protection
Yes
Type of electrical connection of main circuit
Screw connection
Type of control element
Rocker lever
Switch off technique
Electronic
Rated operation power at AC-3, 230 V
0.75
Rated short-circuit breaking capacity Icu at 400 V, AC
50
Adjustment range undelayed short-circuit release
60
60
Phase failure sensitive
Yes
Device construction
Complete device in housing
Brands
Schneider
