Univ IP44 a1850100 l800 p205
Cabinets
Univ IP44 a1850100 l800 p205
Manufacturer Ref:
FP23SN2
Nortécnica Ref:
71FP23SN2
EAN:
3250612668960
Description
Technical Information
Attributes
Mounting method
Floor installation
EF000004
II
Colour
White
Width
800
Height
1950
Depth
205
RAL-number
9010
With mounting plate
No
Surface protection
Powder coating
Built-in depth
205
Number of rows
12
Type of covering
Cover
Number of conduit inlets
6
Extension possible
Yes
Inner depth
143
Housing material
Steel
Circuit integrity
None
Width in number of modular spacings
36
Suitable for outdoor use
No
Impact strength
IK09
Number of modules
432
Type of door
Single
Degree of protection IP
IP44
Transparent coverdoor
No
With lock
No
Suitable for lightning protection
No
Nominal current In
400
Material plate thickness cabinet
1
Material plate thickness doorcover
1
Cover model
Closed
Number of openings for flange plates
6
Degree of protection NEMA
-
Cover with overpressure release
No
Brands
Hager Sistemas Eléctricos Modulares SA
Technical Sheet
