Power supply unit for permanent load Primary 85..265 V AC, 85..300 V DC Secondary 24 V DC +-5% Overall width 2MW Short-circuit and overload protection Electronic power supply units for the supply of DC power to electrical devices. The electronic power supply unit provides a 24 V DC supply to systems with an operational voltage of 85 to 265 V AC or 85 to 300 V DC. The device operates in the lower class for minimum power supply with a safety extra-low voltage (SELV). Whether for infrastructure or for industrial requirements, Siemens provides safety transformers for all applications and every application area. Key features of the network devices from Siemens: 1. User-friendly and easy installation and connection technology. 2. Reliable safety during installation with standard touch protection. 3. Integrated short-circuit and overload protection. 4. Optimized safe power supply technology for your safety – only from Siemens.
Management and Measuring Devices
Power supply unit for permanent load, primary 85..265 V AC, 85..300 V DC seco...
Nortécnica Ref:
EAN:
4001869370569
Description
Technical Information
Attributes
Width
36
Height
64
Type of transformer
Mains transformer
With onoff switch
No
Suitable for distribution board
Yes
Max. output current
0.35
Length
90
Max. output power
8.4
Width in number of modular spacings
2
Surface mounting
No
Short-circuit protected
Yes
Primary voltage
265
Secondary voltage 1
24
Secondary voltage 2
0
Secondary voltage 3
0
Secondary amperage 1
0.35
Secondary amperage 2
0
Secondary amperage 3
0
Temperature protection
Yes
Max. power loss
0
Flush-mounted installation
No
Brands
SIEMENS
Long Description
Power supply unit for permanent load Primary 85..265 V AC, 85..300 V DC Secondary 24 V DC +-5% Overall width 2MW Short-circuit and overload protection Electronic power supply units for the supply of DC power to electrical devices. The electronic power supply unit provides a 24 V DC supply to systems with an operational voltage of 85 to 265 V AC or 85 to 300 V DC. The device operates in the lower class for minimum power supply with a safety extra-low voltage (SELV). Whether for infrastructure or for industrial requirements, Siemens provides safety transformers for all applications and every application area. Key features of the network devices from Siemens: 1. User-friendly and easy installation and connection technology. 2. Reliable safety during installation with standard touch protection. 3. Integrated short-circuit and overload protection. 4. Optimized safe power supply technology for your safety – only from Siemens.
